Move to selected layer - move (change) all objects in the selected layer to the new selected layer.Move to current layer - move (change) selected objects to the current layer.for returning from the Isolate layer or Freeze xref commands) Delete layer - deletes all objects(!) laying in the layer you select by picking.

Laying on that layer (only objects laying in this layer will remain on the screen)

Isolate layer - freezes all layers except that selected by picking an object.

Off by pick - switches off the layer you select by picking an object laying on that layer.

Freeze by pick - freezes the layer you select by picking an object laying on that layer.

You can click the last button (with white rectangle) in the flyout to display a separate toolbar for the command group.Īn older Flash demo - using LT Extension The first part of the LT Extension toolbar contains layer functions. The application consists of a toolbar containing several flyouts with command groups. This is only a first time operation - the toolbar will loadĪutomatically in all your subsequent AutoCAD LT sessions. LT Extension toolbar should appear in your AutoCAD window. Load the LText.mns or the CUIX ribbon as a partial menu (do not rename it). IMPORTANT (first time only): Launch AutoCAD LT and enter the _MENULOAD or _CUILOAD command. In other cases copy all files from the distribution archive to your AutoCAD LT support directoryĬ:\Program Files\AutoCAD LT 2002\Support orĬ:\Documents and Settings\ user_name\Application Data\Autodesk\AutoCAD LT 2010\R15\enu\Support or C:\Users\ user_name\AppData\Roaming\Autodesk\AutoCAD LT 2020\R26\enu\Support). Both 32-bit and 64-bit versions of AutoCAD LT are supported in Windows XP, Vista, Win7, Win8/8.1 and Win10 (32/64). With any language version of AutoCAD LT (and full AutoCAD).

LT Extension is an add-on application by Arkance Systems (CAD Studio) which adds a number of useful functions to your AutoCAD LT (or AutoCAD) toolbar.
